Commissioning Completed For A 600 M2 Sinter Cooler Waste Heat Boiler (Largest In China)

Views:0     Author:Site Editor     Publish Time: 2016-11-21      Origin:Site

On September 24, 2015, JSDJ was awarded a contract (847 million RMB) from Bao-steel Corp to design and manufacture a Waste Heat Recovery Unit for one of the largest Sinter Plants in the world. Our scope of supply mainly included steel frame, platforms. Staircases. duct connections, pre-fabricated heat surface modules, steam drum, piping system, instruments & valves, spare parts, etc. All components had been manufactured and delivered on September 7, 2016. This project was successfully comissioned on November 6th, 2016.



Key Parameters



Max Power Output: 33MW

Inlet gas temp: 400 / 350 / 300 Celsius

Outlet gas temp: 136 Celsius

Steam pressure: 1.8 / 0.5 MPA

Steam temp: 270 / 180 Celsius

Steam output: 80 & 20 T / H



This project confers a significant honor on JSDJ as the Sinter Plant is currently the largest (600 m2) in China. Not only do we give our sincere thanks to Bao-steel for awarding us a project of such significance, we also extol its continuity in being a paragon of environmental virtue.

Baosteel-600m2Baosteel-600m21Baosteel-600m22
